Low Pass Inline 3 Phase Emi Filter For Air Conditioner high quality

Name: Low Pass Inline 3 Phase Emi Filter For Air Conditioner high quality
Brand: changzhou hezi international trading co.,ltd.
Price: 150.00 USD
Availability: InStock

High Light

air conditioner 3 phase emc filter, Low Pass 3 phase emi filter, air conditioner inline emi filter

Type

EMI Filter

Transfer Function

Low Pass

Package Type

Throught Hole

Nominal Center Frequency

50/60Hz

3dB Bandwidth

Insertion Loss

100dB

Input Impedance

50ohm

Stopband Attenuation

70-100dB

Rated Voltage

250VDC

Rated Current

3A 5A 10A

LINES NUMBER

Application

Air Conditioner

Test Voltage

G-L 1000VDC L-L 1000VDC

Shieling Effective

100dB @ 14K-10GHz

Port

Changzhou Shanghai Hangzhou Or Others

Place of Origin

Jiangsu, China

Brand Name

nenglv

Certification

Model Number

SF-K6

Minimum Order Quantity

>=1 Pieces

Packaging Details

8 PCS IN ONE CARTON THE GROSS WEIGHT OF ONE CARTON IS ABOUT 18KG

Supply Ability

100 Piece/Pieces per Week

$150.00

Get The Latest Quote

Description

6 lines 3A emi signal emi filter for Air conditioning signal line anechoic chamer

What is a power line filter?

Power line filter is electrical equipment which effectively filters particular frequency point in the power line or the frequency out of the particular frequency point. Power line filter performance is to get a certain frequency power supply signal or power supply signal after eliminating a certain frequency through connecting power supply filter in power line. Based on this performance of power line filter, a square wave group or compound noise wave could be converted into a certain frequency sine wave through power line filter.

Power supply filter is a passive bi-directional network, that is, one end is power supply, and the other end is load. Power supply filter principle is a impedance adaption network: the larger the impedance mismatching is (between “power filter input&output” and “power & load” side), the more effective the attenuation of electrical magneto interference is.

Product Description

RATED VOLTAGE	250 VDC
RATED CURRENT	3A 5A
PASS BAND	7K
LINES NUMBER	6

General purpose 3A 1-phase single-stage EMI power line filter, rated voltage 115/250V AC 50/60Hz, high performance for noise suppression with compact size, easy mounting, and low price. EMI line/noise filter, 1-phase 1-stage, rated current 3A and rated voltage 250V AC, has a wide range of applications like electrical equipment, electronics, household appliances, and office equipment with its good differential mode and common mode attenuation performance.

We are a professional and famous EMI filter manufacturer.
Our technical team has more than 10 years’ experience in designing EMI filter. We know UL VDE CSA CE CQC etc safety standard very well.
Our technical service team learn many kinds of test standard such as industrial application (IEC61800-3 for frequency inverter drive EN12015 for elevator EN55011 for ISM device etc) and military application (GJB151A GJB152A etc).We can solve EMI problem quickly effectively and low-costly.

Before-sale:
1.All inquires will be replied with 8 hours. 7D/24H service,Please feel free to contact us with Email/TM/Skype.
2.Strong technical team and Professional sales.
3.Customized packaging is acceptable.
4.Welcom customers from all the world to visit our factory.
After-sale:
1.All emi filter will be tested and adjusted before shipping.
2.After receiving the products,Any question we will try our best to solve.
