Targeted EMI Shielding Solution for Industrial and Electronics Applications
Designed specifically for engineering professionals and system integrators, this copper foil tape provides a reliable method for mitigating electromagnetic interference in electronic assemblies. It serves users requiring effective shielding alongside advanced emi filter circuits, especially in equipment sensitive to RF noise. Our solution targets customers needing seamless integration with existing emi filters, facilitating robust EMI suppression in prototype and production stages. This product supports engineers aiming for compliance with strict EMC standards, providing a practical adjunct to emi filter manufacturer portfolios focused on industrial reliability.
Precision Copper Construction and Verified Shielding Performance
This copper foil tape features a 99.8% purity copper substrate with conductive acrylic adhesive, measuring 0.105 mm or 0.14 mm in thickness. It ensures stable, low-resistance electrical contact at joints and contours, compatible with advanced emi filters in sophisticated setups. Shielding effectiveness is quantified at ≥60 dB across 10 MHz to 1 GHz, meeting critical suppression benchmarks. Flexibility in width and length options enables fine customization, supporting design variances encountered by emi filter manufacturers aiming for optimal circuit integration and diminished EMI emissions.
Critical Utility in EMI-Sensitive Electronics and RF Enclosures
The tape’s applicability spans RF-sensitive enclosures, antenna compartments, and instrument panels where integration with proven emi filters enhances overall system EMI attenuation. It is particularly valuable in shielding cable junctions, guitar cavity modifications, and Faraday cage linings, delivering stable interference suppression in demanding test and operational environments. This copper foil tape complements single phase emi filter manufacturers efforts to improve performance in control systems, medical instruments, and communication devices, effectively reducing noise and ensuring EMC compliance.
Electromagnetic Shielding Copper Foil For MRI Room
| Product description | |
| Name | copper foil |
| Material | 99.8% copper |
| Width | standard 1350mm |
| Thickness | standard 0.105mm(3oz),0.14mm(4oz) |
| Feature | EMI shielding |
| Application | faraday cage,MRI room |
Product description:
1. The product structure is based on copper foil as the substrate, conductive acrylic adhesive as the adhesive, plus release paper.
2. Three-tier architecture is very suitable for cutter mold or the metal mold die-cutting, Can be flat cutter or round cutter to die-cutting.
3. The width of the product available from 3mm ~ 380mm. Standard length is 50m., also do 100m, 150m or longer, save customers the trouble of frequently reloading.
| Part Number | Backing Material | Thickness of Backing (mm) | Total Thickness (mm) | Holding Power Min/inch | Adhesion Strength kg/25mm | Adhesive Component | Shield Efficacy 10MHz~ 1GHz (dB) | Conductivity z-ohms | Integrated thermal conductivity (W/mK) |
| XPH0M123 | Copper Foil | 0.012 | 0.030±0.01 | ≥1440 | >0.8 | Acrylic | ≥60 | <0.03 | 60 |
| XPH0M183 | Copper Foil | 0.018 | 0.050±0.005 | ≥1440 | >1.0 | Acrylic | ≥60 | <0.03 | 60 |
| XPH0M253 | Copper Foil | 0.025 | 0.06±0.005 | ≥1440 | >1.0 | Acrylic | ≥60 | <0.03 | 80 |
| XPH0M353 | Copper Foil | 0.035 | 0.070±0.005 | ≥1440 | >1.0 | Acrylic | ≥60 | <0.03 | 90 |
| XPH0M503 | Copper Foil | 0.050 | 0.085±0.005 | ≥1440 | >1.0 | Acrylic | ≥60 | <0.03 | 110 |
| XPH0M753 | Copper Foil | 0.075 | 0.11±0.01 | ≥1440 | >1.0 | Acrylic | ≥60 | <0.03 | 130 |
| XPH0MA03 | Copper Foil | 0.100 | 0.135±0.01 | ≥1440 | >1.0 | Acrylic | ≥60 | <0.03 | 160 |
| XPH0MA23 | Copper Foil | 0.125 | 0.15±0.015 | ≥1440 | >1.0 | Acrylic | ≥60 | <0.03 | 170 |
| XPH0MA53 | Copper Foil | 0.150 | 0.20±0.02 | ≥1440 | >1.0 | Acrylic | ≥60 | <0.03 |
190
|
Product Advantages
Innovative Design and Modular Compatibility with EMI Systems
Our copper foil tape exhibits superior design fit for modular EMI suppression strategies, offering flexible widths and lengths to adapt to diverse enclosure geometries. It facilitates streamlined integration with emi filter circuits, improving static grounding and shielding continuity. The conductive adhesive assures consistent contact resistance, a vital attribute for systems requiring continuous, reliable EMI mitigation. Manufacturers focused on single phase emi filter manufacturers and complex EMI assemblies benefit from its adaptable application, enabling scalability and easing installation challenges in compact or irregular designs.
Superior Shielding Performance Ensuring System Stability and Compliance
This solution provides exceptional shielding effectiveness crucial for preserving functional integrity of sensitive electronics. Its high-purity copper and conductive adhesive jointly reduce electromagnetic leakage and crosstalk, facilitating compliance with industrial EMI standards. The tape’s ease of application advances user efficiency, complementing emi filters by maintaining stable circuit environments under variable operating conditions. It supports engineering efforts in reducing downtime and increasing equipment longevity through targeted EMI suppression, promoting measurable performance gains.
| Product Features |
| shielding ED copper foil |
| thickness 0.009--3mm, width 10-1380mm |
| easier to make a faraday cage, EMI room |
| generally 400-500kg/roll |
| Physical Properties |
| Density:8.9g/cm³ |
| Electrical conductivity(20°C):min 90%IACS for annealed to temper 80%IACS for rolled to temper min |
| Thermal conductivity(20°C):390W/(m°C) |
| Elastic modulus:118000N/m |
| Softening temperature:≥380°C |
| Certification |
| meet the technical conditions GB/T 5187-2008 standards. |
|
in accordance with ISO9001-2000 Quality system requirements |
Use Scenarios
Shielding RF-Sensitive Audio and Instrument Electronics
In professional audio and musical instrument manufacturing environments, this copper foil tape plays a central role in mitigating RF interference and hum noise within guitar cavities and amplifier enclosures. It functions as a critical adjunct to integrated emi filters, enhancing noise reduction in sensitive control cavities and pickups. By addressing EMI leakage points effectively, it contributes to improved signal integrity and fidelity. Integration with existing shielding strategies enables manufacturers to meet stringent EMC requirements while maintaining design flexibility for custom instrument fabrication.
Application in Electronic Enclosures for Industrial Automation
Within industrial automation systems, where reliable signal processing and control are paramount, this copper foil tape addresses enclosure shielding needs by physically complementing embedded emi filter circuits. It reduces EMI from power inverters, servo drives, and frequency converters, ensuring stable operation of industrial controllers and sensors. By lining seams, joints, and interior surfaces of enclosures, it strengthens the overall shielding performance, facilitating compliance with IEC and other relevant EMC standards. This product enhances the shielding efficacy achievable by trusted emi filter manufacturers supporting automation equipment manufacturers.
What materials are used in Emi Shielding Copper Foil Tape, and how do they ensure effectiveness?
The tape features a copper foil backing made of 99.8% pure copper combined with a conductive acrylic adhesive. This combination provides solid electrical contact and ensures effective EMI shielding, achieving shielding performance of ≥60 dB across 10 MHz to 1 GHz frequencies, suitable for precise EMI filter applications.
Can Emi Shielding Copper Foil Tape be customized to fit specific project requirements?
Yes, the tape is available in widths from 3 mm to 1350 mm and roll lengths up to 150 meters or longer. It can be die-cut or trimmed to fit curved or irregular shapes, making it ideal for various industrial shielding needs. For bulk orders, please inquire about customized dimensions to suit your EMI filter manufacturing requirements.
What are the recommended applications for Emi Shielding Copper Foil Tape in electronics?
This tape is commonly used for shielding guitar cavities, electronic enclosures, and instrument panels to reduce RF interference. It supports EMI filter circuit integrity by minimizing noise in frequency inverters, servo drives, and other sensitive devices. It is also suitable for constructing Faraday cages and EMI rooms.
How does the delivery and packaging of Emi Shielding Copper Foil Tape ensure product safety?
Standard roll lengths include 50 meters with options for larger quantities. Packaging comes in wooden cases to protect against damage during transit. Typical delivery times are 5–7 days, and shipments are tracked via reliable couriers to ensure timely receipt for EMI filter manufacturers and industrial users.
